Part Number | Maximum Allowable Voltage | Varistor Voltage | Maximum Clamping Voltage | Surge Operating Duty Test IEC 61643-11(8/20μs) | Impulse Current(10/350μs) | ||||
VAC | VDC | V1mA(V) | IP(A) | VC(V) | Imax | In | Iimp 1time | ||
34SK201T | 130V | 170V | 200(180~220) | 300 | 340 | 100KA | 40KA | 12.5KA | |
34SK221T | 140V | 180V | 220(198~242) | 300 | 360 | 100KA | 40KA | 12.5KA | |
34SK241T | 150V | 200V | 240(216~264) | 300 | 395 | 100KA | 40KA | 12.5KA | |
34SK271T | 175V | 225V | 270(243~297) | 300 | 455 | 100KA | 40KA | 12.5KA | |
34SK301T | 190V | 250V | 300(270~330) | 300 | 500 | 100KA | 40KA | 12.5KA | |
34SK331T | 210V | 275V | 330(297~363) | 300 | 550 | 100KA | 40KA | 12.5KA | |
34SK361T | 230V | 300V | 360(324~396) | 300 | 595 | 100KA | 40KA | 12.5KA | |
34SK391T | 250V | 320V | 390(351~429) | 300 | 650 | 100KA | 40KA | 12.5KA | |
34SK431T | 275V | 350V | 430(387~473) | 300 | 710 | 100KA | 40KA | 12.5KA | |
34SK471T | 300V | 385V | 470(423~517) | 300 | 775 | 100KA | 40KA | 12.5KA | |
34SK511T | 320V | 415V | 510(459~561) | 300 | 845 | 100KA | 40KA | 12.5KA | |
34SK561T | 350V | 460V | 560(504~616) | 300 | 925 | 100KA | 40KA | 12.5KA | |
34SK621T | 385V | 505V | 620(558~682) | 300 | 1025 | 100KA | 40KA | 12.5KA | |
34SK681T | 420V | 560V | 680(612~748) | 300 | 1120 | 100KA | 40KA | 12.5KA | |
