Part Number | Maximum Allowable Voltage | Varistor Voltage | Maximum Clamping Voltage | Surge Operating Duty Test IEC 61643-11 (8/20μs) | Safety Certification | ||||
 | VAC(V) | VDC(V) | V1mA(V) | IP(A) | VC(V) | Imax | In | UL | |
50 | 65 | 82 (73.8~90.2) | 150 | 135 | 20KA | 10KA | - | ||
60 | 85 | 100 (90~110) | 150 | 165 | 20KA | 10KA | - | ||
75 | 100 | 120 (108~132) | 150 | 200 | 20KA | 10KA | - | ||
95 | 125 | 150 (135~165) | 150 | 250 | 20KA | 10KA | - | ||
115 | 150 | 180 (162~198) | 150 | 300 | 20KA | 10KA | - | ||
130 | 170 | 200 (185~225) | 150 | 330 | 20KA | 10KA | √ | ||
140 | 180 | 220 (198~242) | 150 | 360 | 20KA | 10KA | √ | ||
150 | 200 | 240 (216~264) | 150 | 395 | 20KA | 10KA | √ | ||
175 | 225 | 270 (243~297) | 150 | 455 | 20KA | 10KA | √ | ||
190 | 250 | 300 (270~330) | 150 | 505 | 20KA | 10KA | √ | ||
210 | 275 | 330 (297~363) | 150 | 550 | 20KA | 10KA | √ | ||
230 | 300 | 360 (324~396) | 150 | 595 | 20KA | 10KA | √ | ||
250 | 320 | 390 (351~429) | 150 | 650 | 20KA | 10KA | √ | ||
275 | 350 | 430 (387~473) | 150 | 710 | 20KA | 10KA | √ | ||
300 | 385 | 470 (423~517) | 150 | 775 | 20KA | 10KA | √ | ||
320 | 415 | 510 (459~561) | 150 | 845 | 20KA | 10KA | √ | ||
350 | 460 | 560 (504~616) | 150 | 920 | 20KA | 10KA | √ | ||
385 | 505 | 620 (558~682) | 150 | 1025 | 20KA | 10KA | √ | ||
420 | 560 | 680 (612~748) | 150 | 1120 | 20KA | 10KA | √ | ||
460 | 615 | 750 (675~825) | 150 | 1240 | 20KA | 10KA | √ | ||
485 | 640 | 780 (702~858) | 150 | 1290 | 20KA | 10KA | √ | ||
510 | 670 | 820 (738~902) | 150 | 1355 | 20KA | 10KA | √ | ||
550 | 745 | 910 (819~1001) | 150 | 1500 | 20KA | 10KA | √ | ||
625 | 825 | 1000 (900~1100) | 150 | 1650 | 20KA | 10KA | - | ||
680 | 895 | 1100 (990~1210) | 150 | 1815 | 20KA | 10KA | - | ||
